Boom Lifts Q
1. Better suited for leased fleet construction, with excellent performance, safety, and reliability. Designed for both end users and rental users, it aims to help customers recover costs in the shortest time, optimize fleet configuration, and enhance competitiveness. The product is extremely lightweight and energy-efficient, compact, and has excellent endurance. The HJQ1416 features an intelligent and complete control system, a user-friendly layout, lubrication-free design, and is easy to use and maintain; it provides comprehensive safety protection and a wide range of configuration options. 2. The “Σ-type” combination boom has a compact structure, flexible extension, and can achieve vertical lifting and horizontal extension, with excellent obstacle-crossing ability; the 160° rotating platform provides a larger working range; the narrow turntable with a compact layout improves operational efficiency, can switch to storage mode, and uses an aluminum alloy work bucket that is easy to assemble and disassemble. 3. Full-range operation, intuitive and user-friendly control panel, simple operation; precise and efficient electro-hydraulic proportional system control. Provides chassis tilt protection, emergency descent, safety speed limits, flexible start-stop technology, and other protective measures.
Note: Product specifications are subject to periodic adjustments or updates. The specifications on this website are for reference only; the actual specifications shall prevail.
| Name | Parameter | ||
| Brand and Model | Brand | Huaju | |
| Model | HJQ1618 | ||
| Size | Working Height | 17.6m | |
| Platform Height | 15.6m | ||
| Maximum Jump Height | 7.2m | ||
| Maximum Working Radius | 8.8m | ||
| Platform size (length and width) | 1.4*0.76m | ||
| Overall Vehicle Dimensions (Length × Width × Height) | 6.9*2.25*2m | ||
| Wheelbase | 2.3m | ||
| Ground Clearance | 0.28m | ||
| Performance | Maximum Load | 230kg | |
| Platform Rotation | ±80° | ||
| Turntable rotation | 355° | ||
| Short-arm vertical rotation | ±70° | ||
| Driving speed | 5km/h | ||
| Climbing ability | 30% | ||
| Maximum allowable angle during work | 3° | ||
| Platform capacity | 2 | ||
| Turning radius - outer side | 4.7m | ||
| Drive Steering Type | 2×2 | ||
| Tire | 250-15 | ||
| Overall machine weight | 5730kg | ||
| Power | Battery | 48V/320Ah | |
| Control voltage | 24V | ||
| Pump motor power | 4kw | ||
| Travel motor power | 3.3kw | ||
| Charger | 48V/20A | ||
| Hydraulic oil tank | 25L | ||
| Optional | Lithium battery | Optional | |
| Color | Optional | ||
1. Better suited for leased fleet construction, with excellent performance, safety, and reliability.
Designed for both end users and rental users, it aims to help customers recover costs in the shortest time, optimize fleet configuration, and enhance competitiveness. The product is extremely lightweight and energy-efficient, compact, and has excellent endurance.
The HJQ1416 features an intelligent and complete control system, a user-friendly layout, lubrication-free design, and is easy to use and maintain; it provides comprehensive safety protection and a wide range of configuration options.
2. The “Σ-type” combination boom has a compact structure, flexible extension, and can achieve vertical lifting and horizontal extension, with excellent obstacle-crossing ability; the 160° rotating platform provides a larger working range; the narrow turntable with a compact layout improves operational efficiency, can switch to storage mode, and uses an aluminum alloy work bucket that is easy to assemble and disassemble.
3. Full-range operation, intuitive and user-friendly control panel, simple operation; precise and efficient electro-hydraulic proportional system control. Provides chassis tilt protection, emergency descent, safety speed limits, flexible start-stop technology, and other protective measures.
